Frame: Bianchi T-Tronik Sport, AL6061 triple butted, 1.5 taperedHT, seatpost diam. 31,6mm, seat clamp diam. 34.9, PM160mm dropout, Boost QR 12x141mm, internal cablerouting inside DT, sizes 38, 43, 48, 53cm
Fork: SR Suntour XCR34 AIR Boost LOR DS 29 120mm, withLOR, 1.5 tapered HT, alloy crown, Air spring w/pre-loadadjust, 34mm stanchions, PM 180mm disc mount, thruaxle 15x110mm
Brakes: Shimano BR-MT410, resin pad
Stem: Tec Obvius forged alloy 6061, +/-7°, 1.1/8 , 31.8mm, ext:60mm-15/19 , 70mm-21
Handlebar: Tec rise, DB Alloy 6061-T6, width 740mm, diam. 31,8mm, 9°backsweep, 15mm rise
Saddle: Tec Rector, 140mm width, Steel rails, Pvc soft touch cover
Seatpost: Tec AL2014 shaft and alloy head, diam 31.6mm, 0mmsetback, length: 350mm-15/17”, 400mm-19/21”
Rear Derailleur: Shimano Deore RD-M5120 SGS 10sp
Shifters: Shimano Deore SL-M4100-R 1x10sp
Rotor: Shimano SM-RT10 CL, 180mm front & rear, Center Lock
Headset: Fsa Orbit 1.5 ZS #57 w/internal alloy cups, ACB bearings1.1/8 Upper, 1.5 Lower, w/8mm cap
Crankset: Fsa Alu, crank length:165 mm, w/Fsa e-bike specific 34T chainring
Chain: Shimano CN-E6090-10, 10sp
Sprocket: Shimano CS-HG500-10, 11-13-15-18-21-24-28-32-37-42T
Wheels: WTB XC25 TCS Tubeless Ready 29 , AL6061-T6, 32 hole
Rear Hub: Shimano FH-MT200-B for Center Lock, 32h, BOOST141
Front Hub: Shimano HB-MT400-B for Center Lock, 32h thru axle15x110mm
Tires: Wtb Slick 2.2 29 54/54 27tpi Casing, Wire Bead
Quick Stand: Ursus R78 King rear, 28
Rear Carrier: Atranvelo Commute 28 w/AVS system
Front Light: Spanninga Axendo 40, E-bike 6-36VDC Xe 40 Lux, 1 whiteLed
Rear Light: Spanninga Pimento XE 6-36 VDC
Bottom Bracket: Included w/motor unit
Motor: Bianchi Motor Unit 250W 85Nm w/Phylion 504Whintegrated battery
Grip: T-One Rock T-GP34 single lock grip , TPR, plastic innerbody, aluminium clamp
Mudguard: Alloy Mudguards EVO M75/29
